• Deep drawn steel shells for maximum material strength
• Inner shell prevents diaphragm from over expanding
• Heavy duty diaphragm of butyl rubber, separates air and water, maintains air change
• Standard models feature durable polypropylene liner, meets FDA requirements
• Mounted pump models feature fusion bonded polymeric lining, meets FDA requirements
• Maximum working pressure - 125 PSI (except mounted pump models, 100 PSI)
• Temperature rating maximum - 140 degrees F
• Stainless steel system connection on all standing, in-line buried models
• Appliance appearance exterior finish - two coat high performance protection system
• Heavy duty base eliminates corrosion due to condensation and exposure to the elements, made of high density polypropylene

Capacity 4.5 gal
Catalog Number V15P
Connection Size 3/4 in
Connection Type NPTM
Height 13-15/16 in
Material Steel
Maximum Operating Temperature+140 deg F
Mounting Type In-Line
Operating Pressure Rating 125 PSI
Order Number V15P
Outside Diameter 11 in
Resistance Properties/Features Corrosion-Resistant
Shape Round
UPC 697666351050
Weight 10 lb.
