• Modular cartridge design reduces the number of parts requiring service
• Quick and Easy Services / Repair
• Rugged bronze body: Superior reliability, Improved user safety
• Compact pressure reducing and regulating valves
• Designed for small and economic considerations
• Certified to ASSE standard 1003 and CSA standard B356
• Listed by IAPMO and ASSE and certified lead-free complying with NSF 372 Inspector friendly for peace of mind
• By-pass mechanism integral with the cartridge
• No add-on or small parts, longer life and more reliable performance
• Every valve is tested for performance prior to shipping
• Specify and install with confidence
• Assembled and tested in the USA

3/4" EB45-U Single union threaded pressure reducing valve. * Maximum temperature 180 D, * Maximum inlet pressure 400 PSI (1/2", 3/4" and 1"), * Service - Water, * Outlet pressure range 10-70 PSI, * Body - Lead free bronze, Spring chamber 1/2" and 3/4" Engineered Polymer, 1" - 2" Iron, * Adjusting spring - Steel (Zink plated), * Diaphragm, Reinforced EPDM, * Body seat: 1/2" - 3/4" Polyphenylene Ether + PS, 1" - 2" Polysoulfone, * Seat disc EPDM, * Piston Stainless steel/brass, * Strainer screen: Stainless steel, * "O"-Ring: EP

CashAcmeEB45Usubmittal
